(8aR)-7-(2,3-Dihydro-1,4-benzodioxin-6-ylmethyl)-2-(2-pyridinyl)hexahydroimidazo[1,5-a]pyrazin-3(2H)-one
12729
Reference
(8aR)-7-(2,3-Dihydro-1,4-benzodioxin-6-ylmethyl)-2-(2-pyridinyl)hexahydroimidazo[1,5-a]pyrazin-3(2H)-one Structure
Systematic / IUPAC Name: (8aR)-7-(2,3-Dihydro-1,4-benzodioxin-6-ylmethyl)-2-pyridin-2-yl-5,6,8,8a-tetrahydro-1H-imidazo[1,5-a]pyrazin-3-one
ID: Reference12729
Other Names: NAT50-556019
Formula: C20H22N4O3
Spectral Data
(8aR)-7-(2,3-Dihydro-1,4-benzodioxin-6-ylmethyl)-2-(2-pyridinyl)hexahydroimidazo[1,5-a]pyrazin-3(2H)-one mass spectral data can be found in a separate interface. The data are manually curated and of the highest quality.
Available MS Data
| Used Instruments | Orbitrap Fusion Lumos with ETD LBP |
| No. of Spectral Trees | 1 |
| No. of Spectra | 628 |
| Tandem Spectra | MS1, MS2, MS3 |
| Ionization Methods | NSI |
| Analyzers | FT |
| Last Modification | 8/21/2023 8:25:10 AM |
Identificators
| InChI | InChI=1S/C20H22N4O3/c25-20-23-8-7-22(12-15-4-5-17-18(11-15)27-10-9-26-17)13-16(23)14-24(20)19-3-1-2-6-21-19/h1-6,11,16H,7-10,12-14H2/t16-/m1/s1 |
| InChI Key | LCTLFUILZKUHOY-MRXNPFEDSA-N |
| Canonical SMILES | C1CN2C(CN1CC3=CC4=C(C=C3)OCCO4)CN(C2=O)C5=CC=CC=N5 |
| CAS | |
| Splash | |
| Other Names | NAT50-556019 |
